Bone crushers /broken bone machine

Different models of bone crushers are suitable for crushing fresh and dry bones of cattle,pigs, sheep, donkeys, chicken carcasses, and various other animal bones and fish bones. They can also be used for shredding pigskins, cowhides, and sheepskins, making them ideal equipment for the deep processing of livestock and poultry. The crushing is uniform with a degree of fragmentation ranging from 5 to 80 mm. Special material door devices and sieve mesh sizes can be designed according to the actual needs of customers to adapt to various material shapes and particle sizes.

162 Items sold in last month

Chat Now

Email:coco@songdamachine.com

Product Description

The broken bone machine also called bone crusher, bone shredder, especially suitable for dry processing, fresh cattle bone, pig, sheep and other large animal bone broken bones.

Features:the advantages of simple operation, convenient cleaning and maintenance, compact structure, stable operation, large output, low temperature rise, adjustable particle size, high power motor drive, high efficiency, energy consumption low, can be directly supporting conveyor, automatic feeding, save labor; full PLC control, simple operation, low maintenance cost.

Model	Capacity	Feeding size	Motor	Dimension	Weight
SD-150	20-60kg/h	150*200mm	2.2kw	450720900mm	160kg
SD-230	30-100 kg/h	250*210 mm	4 kw	950630110 mm	230kg
SD-300	80-200 kg/h	300*210mm	5.5 kw	10007001260mm	290 kg
SD-400	150-400 kg/h	380*250 mm	7.5 kw	10808201330	520 kg
SD-500	200-600kg/h	500*250 mm	11-15 kw	17001350176mm0	750-1000 kg
SD-600	300-900 kg/h	600*320mm	22-30 kw	170014801760 mm	1250 kg
SD-700	500-1500 kg/h	700*480mm	37-45 kw	200016002000 mm	1600 kg
SD-800	800-2200 kg/h	800*650 mm	55 kw	160021002620 mm	2500 kg
SD-1000	1000-4000 kg/h	1000*800 mm	75 kw	180021003150 mm	4000 kg
